Presentation
- Great productivity & performance
- Minimized total cost of ownership
- Optimal safety
Specifications
Great productivity & performance
- Dual load capacity: 250 - 350 kg restricted (option)
- 4 wheel drive for excellent rough terrain capabilities
- Quick & simultaneous movements
Minimized total cost of ownership
- Haulotte Activ’Screen: on-board configuration & diagnostic interface
- Easy access to components
- Haulotte Stop Emission System reduces engine and component use
- Reduced engine TCO (power <19 kW : no particulate filter)
Optimal safety
- Smooth & proportional movements for greater precision
- Haulotte Activ’Shield Bar prevents crushing risks (option)
- Haulotte Activ’Lighting System lightens the boom for safe loading in low visibility (option)
| Working height | 16.1 m |
| Platform height | 14.1 m |
| Horizontal outreach | 13 m |
| Lift capacity | 250kg (2 pers.) - option 350kg |
| Platform size | 1.83m x 0.76m |
| Length - stowed | 9.16 m |
| Storage / transport length | 6.68 m |
| Overall width | 2.29 m |
| Height - stowed | 2.47 m |
| Storage / transport height | 3.06 m |
| Vertical jib rotation | 133° (+68°/ -65°) |
| Turntable rotation | 360° continuous |
| Tailswing | 93 cm |
| Wheelbase | 2.35 m |
| Ground clearance | 33 cm |
| Tilt | 5 ° |
| Drive speed | 5.2 km/h |
| Gradeability | 45 % |
| Turning radius - outside | 5.1 m |
| Tyres - solid rough terrain | 850 x 340 mm |
| Engine | Kubota 18.5kW (Stage 5 & NRC) |
| Weight | 7907 kg |
- Haulotte Stop Emission System
- Haulotte Activ'Screen
- 4 Wheel Drive
- Oscillating axle
- Differential : permanent limited slip & operator controlled locking rear differential
- Smooth & proportional movements
- Up to 4 cumulated movements
- Cured-on solid tires
- Swing out engine tray
- Upper control box protection and tool tray
- Motion alarm
- AC power to platform
- Rotating beacon
- Haulotte Activ'Shield Bar
- Haulotte Activ'Lighting System
- Dual load basket capacity 250 - 350kg (restricted enveloppe)
- Large platform 2,44 x 0,91m
- Swing door entry gate
- Power to platform (plug in basket)
- Hydraulic generators 3,5kw or 6,5kW
- Glazier pack
- Pipe rack kit
- Air-line to platform
- Dual USB plug in basket
- Non-marking tires
- Cold weather package
- Hydraulic oil cooler
